Blast Powercore gen4 eW, eColor

Installation Instructions

PDF-000377-01 R04

15 November 2019

Must be installed by a qualified electrician in accordance with all national and local electrical and construction codes and regulations.
Before installing this product, please visit the product page at www.colorkinetics.com for the latest version of the installation instructions. Due to continuous improvements and innovations, installation instructions may change without notice.

  1. Confirm all components received

Gasket ring (attached)
  1. Verify the electrical plan and all necessary surge protection requirements.

Important Surge Protection Requirement: www.colorkinetics.com/KB/surge-protection
Use Configuration Calculator to help identify and locate all luminaires, Data Enabler Pro devices, and controllers and to calculate the number of luminaires each circuit can support based on model, line voltage, circuit load, and cable lengths.

Precision Dimming Luminaires Only

53.3 m (175 ft) maximum individual length
122 m (400 ft) maximum total length
  1. Precision Dimming Luminaires Only - Record location and serial number of each luminaire for addressing

  1. Make sure power is OFF

  2. (Optional) Remove cable

Loosen cable compression

Remove cable lock

  1. Connect luminaires

On/Off Control

Precision Dimming

Line Voltage

  1. Mounting options

Flat surface (customer-supplied hardware)

Indoor junction box (#8-32 screws)

Outdoor junction box (#10-24 screws)

  1. For wet or damp locations, seal all points of entry to prevent water infiltration. Use luminaire gasket (supplied), RTV Silicone, and weatherproof junction boxes

  1. Precision Dimming Luminaires Only - Connect the leader cable

Refer to Data Enabler Pro Installation Instructions for specific mounting and wiring instructions
  1. Turn the power ON.

  2. Precision Dimming Luminaires Only - Address luminaires with QuickPlay Pro software

  3. Attach accessories (Optional)

Attach mounting arm (Optional)

Installation details: see the Mounting Arm Installation Instructions
  1. Aim the luminaires

Do not look into beam.
  1. Lock luminaires in place

Use only hand tools to lock luminaires

Lock rotation screw (2.5 mm) first

Torque setting: 2.82 N-m (25 in-lbf)

Tilt lock screws (5 mm)

Torque setting: 13.5 N-m (120 in-lbf)

  1. Attach safety cable

Ensure that main power supply is off before installing or wiring a luminaire.
Do not attempt to install or use a luminaire until you read and understand the installation instructions and safety labels.
Do not use a luminaire if the lens, housing, or power cables are damaged.
Luminaires have line voltage risk of shock and no user serviceable parts. Do not attempt to open them.
Do not use a luminaire for any voltage for which it is not rated. Do not exceed the specified voltage and current input for any luminaire.
Do not hot swap luminaires. Ensure that power to the series is off before connecting or disconnecting individual luminaires.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: - Reorient or relocate the receiving antenna. - Increase the separation between the equipment and receiver. - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer
This Class B digital apparatus complies with Canadian ICES-005. Cet appareil numerique de la classe B est conforme a la norme NMB-005 du Canada.
220V条件下功率因数≥0.90, 最大电流0.25A.

© 2019 Signify Holding. All rights reserved. Specifications are subject to change without notice. No representation or warranty as to the accuracy or completeness of the information included herein is given and any liability for any action in reliance thereon is disclaimed.
